Brick Slip Tracking Systems

We provide a variety of brick slip tracking system options used as the basis for brick cladding and suitable for internal and external projects on various substrates including brick, block, timber frame/SIPS and ICF. Used to increase the speed of brick slip installation on larger scale projects.



Applications include External Wall Insulation (EWI), refurbishments, modular buildings, leisure and park homes, conservatory wall panels, retail display walls and domestic feature walls.



All of our Brick Slip Tracking System products are non-accredited (not 3rd party certified). You must therefore determine for yourself that adoption of these products within your project is fit for the purpose intended and suitable for use within the scope of any required accreditation.

Tracking Systems Available Online

Brick Slip Tracking Panel - 18mm XPS (1.2m x 0.75m
This tracking system is suitable for 63mm to 67mm brick slips.   Sized to accommodate shipment on a 1.2m x 1.0m pallet or Euro pallet.    Flame Retardant Insulated Brick Slip Tracking System is suitable for in ... (Read More)
£24.59
Brick Slip Tracking Panel - 18mm XPS (1.2m x 2.4m)
This tracking system is suitable for 63mm to 67mm brick slips.   Flame Retardant Insulated Brick Slip Tracking System is suitable for internal and external projects on various substrates including brick, block, timber frame ... (Read More)
£64.60
Brick Slip Tracking Panel - 9mm Fibre Cement Board
This tracking system is suitable for 63mm to 67mm brick slips.   Brick Slip Tracking System based on a BBA approved 9mm Non-combustible Class A1 rated Fibre Cement Board is suitable for internal and external projects on var ... (Read More)
£99.66
Brick Slip Tracking Sheet (1.2m x 0.75m)
This tracking sheet is suitable for 65mm to 67mm brick slips.   Suitable for internal and external projects on various substrates including brick, block, timber frame/SIPS and ICF. Used to increase the speed of brick slip insta ... (Read More)
£11.54
Brick Slip Tracking Sheet (1.2m x 2.4m)
This tracking sheet is suitable for 65mm to 67mm brick slips.   Suitable for internal and external projects on various substrates including brick, block, timber frame/SIPS and ICF. Used to increase the speed of brick slip insta ... (Read More)
£28.64

And don't forget the all important brick slip adhesive

MS55 Brick Slip Adhesive - Recommended adhesive for bonding brick slips to the tracking system.



Can also be applied in dot and dab to the rear of the tracking system to help hold in place whilst applying mechanical fixings.


Product Overview

Download
Brick Slip Tracking System
Product overview - brick slip tracking system adopting horizontal tracking guides to ease brick slip installation
230425_Brick Slip Tracking Panels.pdf
Adobe Acrobat Document 221.4 KB

Tracking sheets also available:

  • In flame retardant ABS
  • In 25mm and 50mm insulation backing
  • In a format suitable for Imperial brick sizes up to 75mm high



Contact 07825 304998 for options, pricing and technical advice on choice of system, fixings and installation.


Fixings Advice

Download
Brick Slip Tracking System Fixing Locations
Recommended fixing method for the brick slip tracking system.
BBSL00021_Brick Slip Tracking System Fix
Adobe Acrobat Document 102.1 KB

Stainless Steel Mudguard Washer
Stainless Steel Mudguard Washer



Used to spread the load at the point of fastening.



E.g. if fixing tracking sheets or insulated panels to a wooden substrate, use M8 x 40mm diameter mudguard washer with an M5 stainless steel wood screw. Length of screw should be appropriate for the thickness of the backing substrate.

Stainless Steel Woodscrew
Stainless Steel Woodscrew



Used to affix the tracking sheet or insulated tracking panel to a wooden substrate.



Use in conjunction with a suitable stainless steel mudguard washer. E.g. if fixing to a timber substrate, use M5 wood screw with an M8 x 40mm stainless steel mudguard washer. Length of wood screw to be appropriate for the thickness of the tracking sheet/panel backing substrate.

Countersunk Lightning Bolt
Countersunk Lightning Bolt



Used to affix the tracking sheet or insulated panel to a concrete substrate.



Use in conjunction with a suitable stainless steel mudguard washer. E.g. if fixing to a concrete substrate, use M6 countersunk lightning bolt with an M10 x 40mm stainless steel mudguard washer. Length of lightning bolt to be appropriate for the thickness of the tracking sheet/panel backing substrate.

Insulation Fixings
Insulation Fixings



Used to affix insulated tracking panels to a block, brick or concrete substrate.



Ensure length selected is appropriate for the thickness of insulation adopted in the tracking panel. E.g. if 17.5mm XPS tracking panel adopted, use 10 x 90mm insulation fixing.



Washer diameter 60mm max.


Fixings available for purchase in tracking panel and tracking sheet store item.



36 fixings per 1200mm x 2400mm tracking sheet recommended.



IF IN DOUBT, SHOUT!



For advise on project specific fixing options call 07825 304998.
